Which equipment and machinery is sa-4335-24-woodward-fuel-shutoff-solenoid compatible with?

Woodward SA-4335-24 Fuel Shutoff Stop Solenoid (sa-4335-24-woodward-fuel-shutoff-solenoid) is compatible with: Case 9040B, Case 9045B, Case 721B, Case 721C, Case 821B, Case 821C, Komatsu PC300-7, Komatsu PC360-7, Komatsu PC350-7, Hyundai R290.

Which engines does part sa-4335-24-woodward-fuel-shutoff-solenoid fit?

Woodward SA-4335-24 Fuel Shutoff Stop Solenoid fits the following engines: Cummins 6CT 8.3L, Cummins 6CTA 8.3L.

What are the OEM and cross-reference part numbers for SA-4335-24?

The OEM and interchange cross-reference numbers for Woodward SA-4335-24 Fuel Shutoff Stop Solenoid include: J930234, 3930234, 3928161, 3964624, 6734-81-9140, 6743-81-9140, SA433524, MXL-1160, SA-4293-24.

What are the technical specifications of sa-4335-24-woodward-fuel-shutoff-solenoid?

Key technical specifications of Woodward SA-4335-24 Fuel Shutoff Stop Solenoid: rated_voltage: 24V DC; coil_configuration: Dual Coil (Pull / Hold); pull_current: 20 A; hold_current: 0.3 A; pull_force: 28 N @ 25 mm; hold_force: 140 N.

Woodward SA-4335-24 Fuel Shutoff Stop Solenoid - Image 1

1 / 2

Woodward SA-4335-24 Fuel Shutoff Stop Solenoid

Express Free Shipping

3-Year Factory Warranty

90-Day Hassle-Free Returns

24/7 Dedicated Support

Rated Voltage	24V DC
Coil Configuration	Dual Coil (Pull / Hold)
pull_current	20 A
hold_current	0.3 A
Pulling Force	28 N @ 25 mm
Hold Force	140 N
Stroke	40-45 mm
Bolt Spacing	3 in (76.2 mm) Center-to-Center
Mounting Type	2-Hole Flange
Connector Type	3-Wire Round Pin Packard
Duty Cycle	Continuous
Operating Temperature	-40°C to +120°C
Ingress Protection	IP67

Manufacturer No.

SA-4335-24SA4335-24FS30E-241752ES-24A2UC3B5S1

OEM Part No.

J9302343930234392816139646246734-81-91406743-81-9140

Engine Part No.

Cummins 6CT 8.3LCummins 6CTA 8.3L

Interchange No.

SA433524MXL-11603930234SA-4293-24

Fitment Vehicles

Case 9040BCase 9045BCase 721BCase 721CCase 821BCase 821CKomatsu PC300-7Komatsu PC360-7Komatsu PC350-7Hyundai R290Hyundai R320Case 8940

Electrical And Electronic Systems - Industrial Encyclopedia

OEM replacement 24V DC dual-coil fuel shutoff stop solenoid SA-4335-24 for Case crawler excavators and wheel loaders with Cummins 6CT 8.3L engines, featuring 3-wire connector and 3-inch bolt spacing.
